UEDA SEISAKUSHO - PL-650-7-R3B

详细参数
品牌	其他	型号	其他

02357984 CR2M16BASA02 NE20E-S16 AC Basic Configuration (Includes NE20E-S16 Chassis,2-MPUE,2-AC Power,Power cord
03031DBV CR2DNSPA0010 Network Service Processor(NSP-A)
Ethernet Line Card
03030QCK CR2D00L2XF11 2-Port 10GBase LAN/WAN-SFP+ Physical Interface Card
03030QCL CR2D00E8GF11 8-Port 100/1000Base-X-SFP Physical Interface Card
03031DKK CR2D0EAGFH10 10-Port 100/1000Base-X-SFP Physical Interface Card H
Optical Transceiver
02310QNG OSC015B01 Optical transceiver,eSFP,Tx 1310nm/Rx 1550nm,155M,-8dBm,-15dBm,-32dBm,LC/PC,SM,15km
02310QXT OSH080N01 Optical Transceiver,eSFP,1550nm,STM4,-3-2dBm,-30dBm,LC,SM,80km
34060639 eSFP-1550/1310-L1.1-BIDI BiDi Transceiver,eSFP,Tx1550nm/Rx1310nm,0.1-1.25Gb/s,-3-2dBm,-25dBm,LC,SM,40km
34060690 OSX070005 Optical Transceiver-SFP+-1551nm-9.95-11.1Gb/s-0dBm-4dBm-23dBm-LC-SM-70km
34060691 OSX070006 Optical Transceiver-SFP+-1571nm-9.95-11.1Gb/s-0dBm-4dBm-23dBm-LC-SM-70km
Power Equipment
02310TLX CR2M0DPUDC11 NE20E-S16 DC Power Distribution Unit
03030RFQ CR5D00PSUD71 DC Power Supply Unit 1600W
NE20E-S2E
Basic Configuration
02311ARG CR2P2EBASD10 NE20E-S2E Basic Configuration (Includes NE20E-S2E Chassis,2-10GE-SFP+ and 24GE-SFP fixed interface,2-DC Power,Fan Box,Power cord
02311ARH CR2P2EBASA10 NE20E-S2E Basic Configuration (Includes NE20E-S2E Chassis,2-10GE-SFP+ and 24GE-SFP fixed interface,2-AC Power,Fan Box,Power cord
02311BQQ CR2M002FBX10 NE20E-S2 Fan Box
31187845 CR2I86DOCE00 HUAWEI NE20E-S2 Universal Service Router Product Documentation
31187920 CR2I87DOCE01 HUAWEI NE20E-S2 Universal Service Router Product Documentation
Non-ethernet Line Card
03030QCN CR2D00C4CF11 4-Port Channelized STM-1c POS-SFP Physical Interface Card(PIC)
03030QCP CR2D000IE111 32-Port E1 Physical Interface Card(120ohm)
03030RET CR2D00P4CF11 4-Port OC-3c/STM-1c POS-SFP Physical Interface Card
Optical Transceiver
34060596 OGEBIDI81 BiDi Transceiver,eSFP,1490nm(Tx)/1570nm(Rx) 1.25Gbps,-2dBm,4dBm,-26dBm,LC,SM,80km
Power Equipment
02311BHJ CR5B2PWRDC00 DC Power Supply Unit 600W
NE20E-S2F
Basic Configuration
02311ARQ CR2P2FBASD10 NE20E-S2F Basic Configuration (Includes NE20E-S2F Chassis,4-10GE-SFP+ and 40GE-SFP fixed interface,2-DC Power,Fan Box,Power cord,without
Installation Material
02231LJU CR2XDCCORD20 NE20E-S4/S8 DC Power Distribution Unit Power Cable package
14130273 SS-OP-LC-FC-M-20 Patch cord-FC/PC-LC/PC-Multimode-A1b-2mm-20m-PVC-Orange
14130282 SS-OP-D-LC-S-30 Patch cord-LC/PC-LC/PC-Single mode-G.652-2mm-30m-PVC-Yellow
25030703 CGND00606 Power Cable,450V/750V,H07Z-K UL3386,6mm^2,Black,58A,LSZH Cable,VDE,UL (Unit:meter)
Optical Transceiver
34060686 OSX070001 Optical Transceiver-SFP+-1511nm-9.95-11.1Gb/s-0dBm-4dBm-23dBm-LC-SM-70km
Power Equipment
02311BLJ CR5B2PWRAC00 AC Power Supply Unit 500W
NE20E-S4
Basic Configuration
02310MSU CR2M004FBX10 NE20E-S4 Fan Box
02350DWY CR2M04BASA01 NE20E-S4 AC Basic Configuration (Includes NE20E-S4 Chassis,1-MPUE,2-AC Power,Power cord
02350DXA CR2M04BASA02 NE20E-S4 AC Basic Configuration (Includes NE20E-S4 Chassis,2-MPUE,2-AC Power,Power cord
02357978 CR2M04BASD02 NE20E-S4 DC Basic Configuration (Includes NE20E-S4 Chassis,2-MPUE,2-DC Power,Power cord
02357980 CR2M04BASD01 NE20E-S4 DC Basic Configuration (Includes NE20E-S4 Chassis,1-MPUE,2-DC Power,Power cord
03030QHA CR2DNSPE5010 Network Service Processor (NSP-50-E, Apply for – 40- 65degree scene)
03031DBX CR2DNSPB0010 Network Service Processor(NSP-B)
31187766 CR5IS300CE02 HUAWEI NetEngine R01S300A Assembly Cabinet Product Documentation
Ethernet Line Card
03030QCM CR2D00E8GE11 8-Port 100/1000Base-RJ45 Physical Interface Card
03030WGQ CR2D00L2XF12 2-Port 10GBase LAN/WAN-SFP+ Physical Interface Card
03031DHB CR2D00E8GE12 8-Port 100/1000Base-RJ45 Physical Interface Card
81400679 CR2S200VXL00 NE20E-S Series VxLan Function License
Non-ethernet Line Card
03030QCQ CR2D000IE110 32-Port E1 Physical Interface Card(75ohm)
03030REY CR2D000DE111 16-Port E1 Physical Interface Card(120ohm)
03030RJQ CR5D08CWDM70 8-Channel Multiplexing Demultiplexing Card
03031DKA CR2DP2C1HF11 2-Port OC-3c/STM-1c (or 1-Port OC-12c/STM-4C) POS-SFP Physical Interface Card
Optical Transceiver
02310VPT OEGD01N02 Optical functional module,1000BASE-T -SFP RJ45Electrical Module,Auto Negotiate,100m ,-40-85degC
02310WQT OMGD55N03 Optical Transceiver,ESFP,850nm,1.25Gb/s,-2.5dBm,-10dBm,-17dBm,LC(-40-85) 0.55km,multimode
02310WQY OECD01N03 Electrical Active Module-Copper Transceiver,SFP,STM-1e
02310WRA OSC015N03 Optical Transceiver,eSFP(industry) 1310nm,STM1,-15–8dBm,-31dBm,LC,SM,15km
02310WRC OSC080N03 Optical Transceiver,eSFP(industry) 1550nm,STM1,-5-0dBm,-37dBm,LC,SM,80k
34060476 eSFP-LH80-SM1571 Optical Transceiver,eSFP,1571nm,100M-2.67Gbps,5dBm,0dBm,-28dBm,LC,80Km
34060480 eSFP-LH80-SM1611 Optical Transceiver,eSFP,1611nm,100M-2.67Gbps,5dBm,0dBm,-28dBm,LC,80Km
34060688 OSX070003 Optical Transceiver-SFP+-1491nm-9.95-11.1Gb/s-0dBm-4dBm-23dBm-LC-SM-70km
34060692 OSX070007 Optical Transceiver-SFP+-1591nm-9.95-11.1Gb/s-0dBm-4dBm-23dBm-LC-SM-70km
S4015755 eSFP-FE-LX-SM1310 Optical Transceiver(eSFP,1310nm,STM1,-15dBm–8dBm,-31dBm,Singlemode,LC,15Km)
S4017483 OSX001002 Optical Transceiver(SFP+,1310nm,10Gb/s,-8.2-0.5dBm,-12.6dBm,LC,SM,10km)
Outdoor Cabinet
02113841 CR5BR01S300A NetEngine R01S300A Assembly Cabinet-CX600-X1/X2(Heat Exchanger)
Power Equipment
02310TLU CR2BPWRACBX0 NE20E-S4 AC Power Box Bundle
02310TLW CR2M0DPUDC10 NE20E-S4/S8 DC Power Distribution Unit
02310YDU R4815G101 R4815G1-15A High Efficiency Rectifier
24021111 WNS005001 Rechargeable Battery,VRLA battery(Front Terminal) 48V,50Ah, battery group(12V Monobloc) 4-(287-108-266)mm,(NorthStar NSB60FT Red)
24021235 WNS010001 Rechargeable Battery,VRLA battery(Front Terminal) 48V,100Ah,battery group(12V Monobloc) 4-(398-108-290)mm,(NorthStar NSB 100FT Red)
24021381 WES010003 Rechargeable battery,VRLA battery(Front Terminal) 48V,100Ah,battery group(12V
NE20E-S8
Basic Configuration
02310MSV CR2M008FBX10 NE20E-S8 DC Fan Box
02310SFU CR2M008FBX11 NE20E-S8 AC Fan Box
02357981 CR2M08BASD02 NE20E-S8 DC Basic Configuration (Includes NE20E-S8 Chassis,2-MPUE,2-DC Power,Power cord
02357982 CR2M08BASA02 NE20E-S8 AC Basic Configuration (Includes NE20E-S8 Chassis,2-MPUE,2-AC Power,Power cord
03030QCX CR2D00MPUE10 Main Processing Unit E
03030QGY CR2D0NSP5010 Network Service Processor (NSP-50)
03030RFG CR2DNSP1201E Network Service Processor (NSP-120-E)
03030RFH CR2DNSP12010 Network Service Processor (NSP-120)
31186588 CR2I20DOCE02 HUAWEI NE20E-S Universal Service Router Product Documentation
31186652 CR5IS300CE01 HUAWEI NetEngine R01S300A Assembly Cabinet Product Documentation
31187618 CR2I20DOCE03 HUAWEI NE20E-S Universal Service Router Product Documentation
31188150 CR2I87DOCE00 HUAWEI NE20E-S Universal Service Router Product Documentation
31188183 CR5IS300CE03 HUAWEI NetEngine R01S300A Assembly Cabinet Product Documentation
Ethernet Line Card
03030REM CR2DL1XE8G10 1-Port 10GBase LAN/WAN-SFP+ + 8-Port 100/1000Base-X-SFP Physical Interface Card
03030REN CR2D00L4XF10 4-Port 10GBase LAN-SFP+ Physical Interface Card(PIC)
03031DJK CR2D00EAGF10 10-Port 100/1000Base-X-SFP Physical Interface Card
03031DJP CR2D00L4XF11 4-Port 10GBase LAN/WAN-SFP+ Physical Interface Card
03031DJQ CR2DL1XE8G11 1-Port 10GBase LAN/WAN-SFP+ + 8-Port 100/1000Base-X-SFP Physical Interface Card
03031DKC CR2D0L2XFH10 2-Port 10GBase LAN/WAN-SFP+ Physical Interface Card H
Non-ethernet Line Card
03030RFA CR2D000DE110 16-Port E1 Physical Interface Card(75ohm)
03031DKB CR2D00C1CF11 1-Port Channelized STM-1c POS-SFP Physical Interface Card
Optical Transceiver
02310RAV OEGD01N01 Optical Functional Module,1000BASE-T-SFP Module,RJ45 Electrical
02310RAW OSG080N01 Optical Transceiver,eSFP,1550nm,1.25Gb/s,-2-5dBm,-23dBm,LC,SM,80km
02310WQW OSG010N03 Optical Transceiver,eSFP,1310nm,1.25Gb/s,-9.5–3dBm,-20dBm,LC(-40-85) SM,10km
02310WQX OSG040N03 Optical Transceiver,eSFP,1310nm,1.25Gb/s,3dBm,-4.5dBm,-22.5dBm,LC(-40-85) 40km
02310WRB OSC040N03 Optical Transceiver,eSFP(industry) 1310nm,STM1,-5-0dBm,-37dBm,LC,SM,40km
34060483 eSFP-LH80-SM1471 Optical Transceiver,eSFP,1471nm,100M-2.67Gbps,5dBm,0dBm,-28dBm,LC,80Km
34060540 OGEBIDI40 Optical Transceiver,eSFP,1490nm(Tx)/1310nm(Rx) 1.25Gb/s,-2dBm,3dBm,-23dBm,LC,SM,40km
34060693 OSX070008 Optical Transceiver-SFP+-1611nm-9.95-11.1Gb/s-0dBm-4dBm-23dBm-LC-SM-70km
Power Equipment
02310RBJ CR5D0PSUAC00 AC Power Supply Unit 1600W
03030QAS CR5D00PSUC70 DC Power Supply Unit 1200W
24020701 6-GFM-50X/H Rechargeable battery,VRLA battery (Front Terminal) 48V,50Ah,battery group(12V Monobloc) 4-(390-105-203)mm
24020813 WES005001 Rechargeable battery,VRLA battery(Front Terminal) 48V,50Ah,battery group(12V Monobloc) 4-(277-106-222)mm
24021101 WSD50AH01 Rechargeable Battery, VRLA battery (Front Terminal) 48V,50Ah, battery group(12V Monobloc) 4-(390-105-200)mm
24021242 WCL010002 Rechargeable Battery,VRLA battery(Front Terminal) 48V,100Ah,battery group(12V Monobloc) 4-(393-108-287)mm
Line Card
03054425 CR5DVSUF8010 Flexible Card Versatile Service Unit 80(VSUF-80)
LPUF-10 Line Card
03030EYA CR53-P10-8×100/1000Base-X-SFP 8-Port 100/1000Base-X-SFP Flexible Card
03030KNE CR5M0E8GFA30 8-Port 100/1000Base-X-SFP Flexible Card A(P10-A,Supporting 1588v2)
LPUF-21 Line Card
03030GSH CR52-P20-12×100/1000Base-X-SFP 12-Port 100/1000Base-SFP Flexible Card
